Model

LTS-721

LTS-721-100

LTS-722

LTS-722N

Optical System

Chromatic aberration elimination (1200 bars/mm grating)

Wavelength Range

350 nm- 1020nm

350 nm- 1020nm

320- 1020nm

320- 1020nm

Spectral Bandwidth

6nm

6nm

5nm

4nm

Wavelength Accuracy

±2nm

Wavelength Repeatability

<=1nm

<=0.5nm

Transmission Accuracy

±1%T

±0.5%T

Drifting

≤0.2%T

≤0.1%T

Photometric Range

0-200%T，-3-3A,0-9999C

Stability

±0.004A/h@500nm

±0.002A/h@500nm

Noise

≤0.3%T

≤0.2%T

Wavelength Setting

Auto

Light Source

Tungsten lamp

Work Mode

T,A,C

Output

N

N

Printer

Printer

Printer Interface

Optional

Dimension(mm)

420*350* 185

N.W(kg)

6

Packing Size(mm)

520*450*300

G.W(kg)

8

1.Digital display of the measured value.

2.Automatic zeroing and automatic adjustment of the hundred.

3.The wide sample chamber can accommodate 5-100mm cuvette.

4.Optional output port RS232, can realize the function of connecting to printer and connecting to computer.

5.The original imported tungsten lamp is used to ensure the service life of the instrument.

6、The instrument adopts the latest microcomputer processing technology, easy to operate.

7、Automatic light gate, to ensure the service life of the photoelectric sensor, the instrument test is more simple.
