Inductively coupled plasma mass spectrometer (ICP-MS) is widely used in universities, quality inspection centers, environmental monitoring stations, enterprises, agricultural systems, geology and mining, environmental protection, geology and metallurgy, electronic and electrical appliances, food safety, chemical and pharmaceutical fields
Specification
Model | LTS-ICP6880 |
Quality And Quantity Range | 2-260amu |
Measuring Range | ≥109 |
Sensitivity | Li≥50;In≤180;U≥200(Mcps/ppm) |
Detection Limit | Li≤2;In≤0.1;U≤0.1(ppt) |
Resolution | 0.2-2.0amu |
Signal-to-noise ratio | ≥50×106 |
Background Noise | 2CPS(Full mass range) |
Mass Axis Stability | ≤0.05amu/24h |
Stability RSD | short-term≤2%; long-term≤3% |
Oxide Ion | CeO﹢/Ce﹢≤2.5% |
Bivalent Ion | 69Ba2﹢/138Ba﹢≤3% |
Lsotope Ratio | (107Ag/109Ag)≤0.2% |
Abundance Sensitivity | ≤1×10-6 Low quality end ≤5×10-7High quality end |
Feature
- Integrated gas path module, reduce gas path joint, lightweight, modular, to ensure that the instrument is easy to move.
- The independently developed solid-state power supply ensures that the instrument can operate in multiple modes (such as conventional mode and cold plasma mode). The well allows multiple modes to operate in the same method, saving a lot of analysis time and facilitating research.
- The adoption of mainstream market design greatly saves the space occupied by the instrument for users, especially third-party test users, and also increases the possibility for future on-board applications.
- Quick switch between Chinese and English software interface, „One-in-one” parameter setting intuitive and fast, improve the user’s work efficiency, but also provide automatic control of instruments and accessories, perfect for Windows professional operating system.
